Samsung Flip WM75A Interactive Display The future of classroom instruction is here with the Samsung.
The messy blackboard is replaced with this touchscreen display, which provides 4K visuals for more engaging lessons and interactive features that increases student engagement. With up to 20-person multi-touch, students can still walk up to write on the “board,” or they can share their mobile screen from their seat with software like Apple’s AirPlay 2.
.
Samsung Flip WM75A Interactive Display 75″ Class 4K UHD Education & Corporate Touchscreen LED Display
The Interactive E-Board Display comes with Realistic Drawing and the Industry’s Fastest Speed with 34ms Latency and 2,048 Points of Screen Pressure
Samsung Flip WM75A Interactive Display transforms the classroom through interactive learning experiences, giving educators the resources needed to create effective and modern lessons. With more software and connectivity options, and intuitive interaction features, Flip 3 creates engaging learning environments.
Unlock creativity with immersive touch technology – Advanced touchscreen technology
Ideate and create with interactive touchscreen technology. Sketch out ideas with swift drawing speed at just 34ms of latency or paint with real-world accuracy with 2,048 points of pressure built directly into the display.
Create and solve without limits – Intuitive and natural drawing
Interactions are intuitively built for problem solving and creating. Use any object near you to bring your ideas to life. Flip 3 distinguishes between inputs from thin or thick objects to simulate on-screen writing or and highlighting. Or simply erase content with your finger or palm.
Minimize accidents and risks – Shatterproof protection
Samsung understands that accidents happen. To protect students and educators, the Flip 3 screen is wrapped in a proprietary shatterproof film, ensuring the screen stays intact in the event of a break.
Centralize lesson plans and school notifications – Open Pluggable
Key Features of Samsung Flip WM75A Interactive Display
- Rotation: NONE – Landscape ONLY
- Diagonal Size: 75″
- Panel Type: New Edge, 60Hz
- Resolution: 3840 x 2160 (Landscape)
- Touch Technology: Infrared
- Number of Touch Points: 20-Point Touch | 4-Point Drawing
- Touch Pen Type: Passive Pen with magnet
- Touch Object Recognition Range: 2mm/ 4mm / 8mm / 50mm(Brush Mode : Dynamic Object Recognition)
- Thickness: 3.2T
- Hardness: Heat Semi-Strengthened Glass
- Additional Film: AG, Hydrophobic Coated PET
- Brightness(Typ.): 350 cd/m2 (without glass)
- Contrast Ratio: 4000:1 (without glass
- Viewing Angle(H/V): 178°/178°
- Response Time(G-to-G): 6ms(Typ.)
- Speaker Type: Built in Speaker (10W x 2CH)
- Software Built-in: Flip App
- Embedded Wi-Fi / Bluetooth Module: Yes
- Input Video: HDMI 2(Rear 1, Front 1), DP 1, OPS I/F
- USB Inputs: 2(For SoC, Rear/Front), 2 (for external 2.0 x1/3.0×1(Front))
- Output Video: HDMI 1 (Screen Share in Front)
- Output Audio: 1(Stereo Mini Jack)
- Touch Out: Touch Out 2 (USB Upstream Type, Front 1, Rear 1)
-
External Control: Touch Input / RS232C thru stereo jack, RJ45(For MDC)
- BT/WiFi: Yes (Keyboard/Mouse)
- Protection Glass: Yes
- Built-In Computer Internal Processor: CA72 Quad(1.7GHz) 2MB L2
- Built-In Computer On-Chip Cache Memory: L2 : 2MB
- Built-In Computer Clock Speed: 1.7GHz CPU Quad
- Built-In Computer Main Memory Interface: LPDDR4 1.6GHz 64bit 3.0GB
- Built-In Computer Graphics: MaliG51 MP4@760MHz
- Built-In Computer Storage (FDM): 16GB
- Built-In Computer IO Ports: USB 2.0
- Built-In Computer Operating System: Tizen 6.0 : Samsung Proprietary OS(VDLinux)
-
Built-In Computer Security Certifications: 802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP
- Power Consumption Max[W/h]: 275
- Power Consumption Stand-by (W): 0.5
- Power Consumption Typical[W/h]: 115
- Rating[W/h]: 250
- BTU(Max): 937.75
- Display Dimensions (WxHxD): 1721 x 1019.3 x 75.2 mm
- Display Weight: 58.3 Kg
- Shipping Dimensions (WxHxD): 1905 x 1182 x 287 mm
- Shipping Weight: 71.7 Kg
- VESA Mounting Pattern: 400mm x 400mm
- Mounting Format: Landscape Only
- Operating Temperature: 0 °C ~ 40 °C
- Operating Humidity: 10% ~ 80% Non-Condensing
- Accessories included: Power Cord, USB Upstream Cable(2ea), Pen(2ea, Black)
- OPS Box (OPS Module not included)
